13-52 SL Controller Action
Array [20]
Option:
3 3
[13] Select preset ref
3
[14] Select preset ref
4
[15] Select preset ref
5
[16] Select preset ref
6
[17] Select preset ref
7
[18] Select ramp 1
[19] Select ramp 2
[20] Select ramp 3
[21] Select ramp 4
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] Dcstop
[27] Coast
[28] Freeze output
134
®
VLT AutomationDrive Programming Guide
Function:
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 3.
If the active preset reference is changed,
it will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 4.
If the active preset reference is changed,
it will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 5.
If the active preset reference is changed,
it will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 6.
If the active preset reference is changed,
it will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 7.
If the active preset reference is changed,
it will merge with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects ramp 1.
Selects ramp 2.
Selects ramp 3.
Selects ramp 4.
Issues a start command to the frequency
converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the frequency
converter.
Issues a quick stop command to the
frequency converter.
Issues a DC stop command to the
frequency converter.
The frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
Freezes the output frequency of the
frequency converter.
MG33MG02 - VLT
13-52 SL Controller Action
Array [20]
Option:
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A
low
[33] Set digital out B
low
[34] Set digital out C
low
[35] Set digital out D
low
[36] Set digital out E
low
[37] Set digital out F
low
[38] Set digital out A
high
[39] Set digital out B
high
[40] Set digital out C
high
[41] Set digital out D
high
[42] Set digital out E
high
[43] Set digital out F
high
[60] Reset Counter A Resets Counter A to zero.
[61] Reset Counter B Resets Counter B to zero.
[70] Start timer 3
[71] Start timer 4
[72] Start timer 5
[73] Start timer 6
[74] Start timer 7
®
is a registered Danfoss trademark
Function:
Starts timer 0, see 13-20 SL Controller
Timer for further description.
Starts timer 1, see 13-20 SL Controller
Timer for further description.
Starts timer 2, see 13-20 SL Controller
Timer for further description.
Any output with SL output A will be low.
Any output with SL output B will be low.
Any output with SL output Cwill be low.
Any output with SL output D will be low.
Any output with SL output E will be low.
Any output with SL output F will be low.
Any output with SL output A will be high.
Any output with SL output B will be high.
Any output with SL output C will be high.
Any output with SL output D will be high.
Any output with SL output E will be high.
Any output with SL output Fwill be high.
Start Timer 3, see 13-20 SL Controller Timer
for further description.
Start Timer 4, see 13-20 SL Controller Timer
for further description.
Start Timer 5, see 13-20 SL Controller Timer
for further description.
Start Timer 6, see 13-20 SL Controller Timer
for further description.
Start Timer 7, see 13-20 SL Controller Timer
for further description.
