Parameter Descriptions
0-30 Unit for User-defined Readout
Option: Function:
[0] None
[1] %
[5] PPM
[10] 1/min
[11] rpm
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
®
VLT AutomationDrive Programming Guide
0-31 Min Value of User-defined Readout
Range:
0 CustomRea-
doutUnit
0-32 Custom Readout Max Value
Range:
100 CustomRea-
doutUnit
0-37 Display Text 1
Range:
0
0-38 Display Text 2
Range:
0
0-39 Display Text 3
Range:
0
3.2.5 0-4* LCP Keypad
Enable, disable and password protect individual keys on
the LCP.
®
MG33MG02 - VLT is a registered Danfoss trademark
[ -999999.99 -
par. 0-32
*
CustomRea-
doutUnit]
[ par. 0-31 -
999999.99
*
CustomRea-
doutUnit]
Function:
[0 - 0 ] Enter a text which can be viewed in the graphical
*
display by selecting [37] Display Text 1 in
0-20 Display Line 1.1 Small, 0-21 Display Line 1.2
Small, 0-22 Display Line 1.3 Small, 0-23 Display Line 2
Large or 0-24 Display Line 3 Large.
Function:
[0 - 0 ] Enter a text which can be viewed in the graphical
*
display by selecting [38] Display Text 2 in
0-20 Display Line 1.1 Small, 0-21 Display Line 1.2
Small, 0-22 Display Line 1.3 Small, 0-23 Display Line 2
Large or 0-24 Display Line 3 Large.
Function:
[0 - 0 ] Enter a text which can be viewed in the graphical
*
display by selecting [39] Display Text 3in
0-20 Display Line 1.1 Small, 0-21 Display Line 1.2
Small, 0-22 Display Line 1.3 Small, 0-23 Display Line 2
Large or 0-24 Display Line 3 Large.
Function:
This parameter sets the
min. value of the custom
defined readout (occurs at
zero speed). Only possible
to set different from 0 is
when selecting a linear unit
in 0-30 Unit for User-defined
Readout. For Quadratic and
Cubic units the minimum
value will be 0.
Function:
This parameter sets the max
value to be shown when
the speed of the motor has
reached the set value for
4-13 Motor Speed High Limit
[RPM] or 4-14 Motor Speed
High Limit [Hz] (depends on
setting in 0-02 Motor Speed
Unit).
