Parameter Descriptions
16-37 Inv. Max. Current
Range:
Size related
*
10000 A]
3 3
16-38 SL Controller State
Range:
0 [0 - 100 ] View the state of the event under execution by
*
16-39 Control Card Temp.
Range:
0 °C [0 - 100 °C] View the temperature on the control card,
*
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see parameter
group 15-1* Data Log Settings). The logging buffer will
never be full when 15-13 Logging Mode is set to [0] Log
always.
[0] No
[1] Yes
16-41 Logging Buffer Full
Range:
0
*
16-48 Speed Ref. After Ramp [RPM]
Range:
0 RPM [-30000 - 30000
*
RPM]
16-49 Current Fault Source
Range:
0 [0 - 8 ] Value indicates source of current faults including
*
152
Function:
[0.01 - View the inverter maximum current,
which should match the nameplate
data on the connected motor. The
data are used for calculation of
torque, motor protection, etc.
Function:
the SL controller.
Function:
stated in °C
Function:
[0 - 0 ]
Function:
This parameter specifies the
reference given to the frequency
converter after the speed ramp.
Function:
short circuit, over current, and phase imbalance
(from left):
1-4 Inverter
5-8 Rectifier
0 No fault recorded
MG33MG02 - VLT
®
VLT AutomationDrive Programming Guide
3.17.3 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0 [-200 - 200 ] View the total reference, the sum of digital,
*
16-51 Pulse Reference
Range:
0 [-200 - 200 ] View the reference value from programmed
*
16-52 Feedback[Unit]
Range:
0 ReferenceFeed-
backUnit
16-53 Digi Pot Reference
Range:
0 [-200 - 200 ] View the contribution of the Digital Potenti-
*
16-57 Feedback [RPM]
Range:
0 RPM
*
®
is a registered Danfoss trademark
Function:
analog, preset, bus and freeze references, plus
catch-up and slow-down.
Function:
digital input(s). The read-out can also reflect
the impulses from an incremental encoder.
[-999999.999 -
999999.999
*
ReferenceFeed-
backUnit]
Function:
ometer to the actual reference.
Function:
[-30000 - Read-out parameter where the actual
30000 RPM] motor RPM from the feed-back source
can be read in both closed loop and
open loop. The feed-back source is
selected by 7-00 Speed PID Feedback
Source.
Function:
View the feedback unit
resulting from the
selection of unit and
scaling in 3-00 Reference
Range, 3-01 Reference/
Feedback Unit,
3-02 Minimum Reference
and 3-03 Maximum
Reference.
