Parameter Descriptions
[6] Running / no Output speed is higher than the speed
warning set in 1-81 Min Speed for Function at Stop
[RPM]. The motor is running and there
are no warnings.
[7] Run in range / Motor is running within the programmed
no warning current and speed ranges set in
4-50 Warning Current Low to 4-53 Warning
Speed High. There are no warnings.
[8] Run on Motor runs at reference speed. No
reference / no warnings.
warning
[9] Alarm An alarm activates the output. There are
no warnings.
[10] Alarm or An alarm or a warning activates the
warning output.
[11] At torque limit The torque limit set in 4-16 Torque Limit
Motor Mode or 4-17 Torque Limit
Generator Mode has been exceeded.
[12] Out of current The motor current is outside the range
range set in 4-18 Current Limit.
[13] Below current, Motor current is lower than set in
low 4-50 Warning Current Low.
[14] Above current, Motor current is higher than set in
high 4-51 Warning Current High.
[15] Out of range Output frequency is outside the
frequency range set in 4-52 Warning
Speed Low and 4-53 Warning Speed High.
[16] Below speed, Output speed is lower than the setting in
low 4-52 Warning Speed Low.
[17] Above speed, Output speed is higher than the setting
high in 4-53 Warning Speed High.
[18] Out of Feedback is outside the range set in
feedback range 4-56 Warning Feedback Low and
4-57 Warning Feedback High.
[19] Below feedback Feedback is below the limit set in
low 4-56 Warning Feedback Low.
[20] Above Feedback is above the limit set in
feedback high 4-57 Warning Feedback High.
[21] Thermal The thermal warning turns on when the
warning temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor, or the thermistor.
[22] Ready, no Frequency converter is ready for
thermal operation and there is no over-
warning temperature warning.
[23] Remote, ready, Frequency converter is ready for
no thermal operation and is in [Auto On] mode.
warning There is no over-temperature warning.
[24] Ready, no Frequency converter is ready for
over-/ under operation and the mains voltage is within
voltage the specified voltage range (see General
Specifications section in the Design
Guide).
[25] Reverse The motor runs (or is ready to run)
clockwise when logic=0 and counter
clockwise when logic=1. The output
®
VLT AutomationDrive Programming Guide
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[40]
[41]
[42]
[43]
[45]
[46]
[47]
[51]
[55]
[60]
®
MG33MG02 - VLT is a registered Danfoss trademark
changes as soon as the reversing signal is
applied.
Bus OK Active communication (no time-out) via
the serial communication port.
Torque limit Use in performing a coasting stop and in
and stop torque limit condition. If the frequency
converter has received a stop signal and
is at the torque limit, the signal is Logic
'0'.
Brake, no brake Brake is active and there are no warnings.
warning
Brake ready, no Brake is ready for operation and there are
fault no faults.
Brake fault Output is Logic '1' when the brake IGBT
(IGBT) is short-circuited. Use this function to
protect the frequency converter if there is
a fault on the brake modules. Use the
output/relay to cut out the main voltage
from the frequency converter.
Relay 123 Relay is activated when Control Word [0]
is selected in parameter group 8-**
Communications and Options.
Mechanical Enables control of an external mechanical
brake control brake, see description in the section
Control of Mechanical Brake, and
parameter group 2-2* Mechanical Brake
Safe stop Indicates that the safe stop on terminal
activated (FC 37 has been activated.
302 only)
Out of ref Active when the actual speed is outside
range settings in 4-52 Warning Speed Low to
4-55 Warning Reference High.
Below Active when actual speed is below speed
reference low reference setting.
Above Active when actual speed is above speed
reference high reference setting
Extended PID
Limit
Bus Ctrl Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. The output state is retained in
the event of bus time-out.
Bus Ctrl On at Controls output via bus. The state of the
timeout output is set in 5-90 Digital & Relay Bus
Control. In the event of bus time-out the
output state is set high (On).
Bus Ctrl Off at Controls output via bus. The state of the
timeout output is set in 5-90 Digital & Relay Bus
Control. In the event of bus time-out the
output state is set low (Off).
MCO controlled Active when an MCO 302 or MCO 305 is
connected. The output is controlled from
option.
Pulse output
Comparator 0 See parameter group 13-1* Comparators.
If Comparator 0 is evaluated as TRUE, the
3 3
