Parameter Descriptions
8-35 Minimum Response Delay
Range: Function:
10 ms [ 1 - 10000 Specify the minimum delay time
*
ms] between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
8-36 Max Response Delay
Range: Function:
Size [ 11 - Specify the maximum permissible
related 10001 ms] delay time between transmitting a
*
request and receiving a response. If a
response from the frequency
converter is exceeding the time
setting then it will be discarded.
8-37 Max Inter-Char Delay
Range: Function:
Size [ 0.00 - Specify the maximum permissible
related 35.00 ms] time interval between receipt of two
*
bytes. This parameter activates time-
out if transmission is interrupted.
This parameter is active only when
8-30 Protocol is set to [1] FC MC
protocol.
3.10.4 8-4* FC MC Protocol Set
8-40 Telegram Selection
Option: Function:
[1] Standard telegram 1 Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1 Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
[202] Custom telegram 3
8-41 Parameters for Signals
Option:
[0] None
®
VLT AutomationDrive Programming Guide
Function:
This parameter contains a
list of signals available for
selection in 8-42 PCD
®
MG33MG02 - VLT is a registered Danfoss trademark
8-41 Parameters for Signals
Option:
[15] Readout: actual setup
[302] Minimum Reference
[303] Maximum Reference
[312] Catch up/slow Down Value
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[411] Motor Speed Low Limit [RPM]
[412] Motor Speed Low Limit [Hz]
[413] Motor Speed High Limit [RPM]
[414] Motor Speed High Limit [Hz]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[590] Digital & Relay Bus Control
[593] Pulse Out #27 Bus Control
[595] Pulse Out #29 Bus Control
[597] Pulse Out #X30/6 Bus Control
[653] Term 42 Output Bus Ctrl
[663] Terminal X30/8 Bus Control
[673] Terminal X45/1 Bus Control
[683] Terminal X45/3 Bus Control
[748] PCD Feed Forward
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[1472] Legacy Alarm Word
[1473] Legacy Warning Word
[1474] Leg. Ext. Status Word
[1500] Operating hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1619] KTY sensor temperature
Function:
Write Configuration and
8-43 PCD Read Configu-
ration.
