Parameter Descriptions
3.18.3 17-5* Resolver Interface
This parameter group is used for setting parameters for
the MCB 103 Resolver Option.
Usually the resolver feedback is used as motor feedback
from Permanent Magnet motors with 1-01 Motor Control
Principle set to Flux with motor feedback.
Resolver parameters cannot be adjusted while the motor is
running.
17-50 Poles
Range: Function:
2 [2 - 8 ] Set the number of poles on the resolver.
*
The value is stated in the data sheet for resolvers.
17-51 Input Voltage
Range: Function:
7 V [2 - 8 V] Set the input voltage to the resolver. The
*
voltage is stated as RMS value.
The value is stated in the data sheet for
resolvers
17-52 Input Frequency
Range: Function:
10 kHz [2 - 15 kHz] Set the input frequency to the resolver.
*
The value is stated in the data sheet for
resolvers.
17-53 Transformation Ratio
Range: Function:
0.5 [0.1 - 1.1 ] Set the transformation ratio for the resolver.
*
The transformation ration is:
V Out
T ratio =
V In
The value is stated in the data sheet for
resolvers.
17-56 Encoder Sim. Resolution
Set the resolution and activate the encoder emulation function
(generation of encoder signals from the measured position from
a resolver). Needed when necessary to transfer the speed or
position information from one drive to another. To disable the
function, select [0] Disabled.
Option:
[0] Disabled
[1] 512
[2] 1024
[3] 2048
[4] 4096
®
VLT AutomationDrive Programming Guide
17-59 Resolver Interface
Activate the MCB 103 resolver option when the resolver
parameters are selected.
To avoid damage to resolvers 17-50 Poles – 17-53 Transformation
Ratio must be adjusted before activating this parameter.
Option:
[0]
[1]
3.18.4 17-6* Monitoring and Application
This parameter group is for selecting additional functions
when MCB 102 Encoder option or MCB 103 Resolver
option is fitted into option slot B as speed feedback.
Monitoring and Application parameters cannot be adjusted
while the motor is running.
17-60 Feedback Direction
Option:
[0] Clockwise
[1] Counter
17-61 Feedback Signal Monitoring
Select which reaction the frequency converter should take in
case a faulty encoder signal is detected.
The encoder function in 17-61 Feedback Signal Monitoring is an
electrical check of the hardware circuit in the encoder system.
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
Function:
[7]
[8]
[9]
[10]
[11]
®
MG33MG02 - VLT is a registered Danfoss trademark
Disabled
Enabled
Function:
NOTE
This parameter cannot be adjusted
while the motor is running.
Change the detected encoder rotation
direction without changing the wiring to
the encoder.
clockwise
Disabled
Warning
Trip
Jog
Freeze Output
Max Speed
Switch to Open Loop
Select Setup 1
Select Setup 2
Select Setup 3
Select Setup 4
stop & trip
3
Function:
Function:
