Parameter Descriptions
NOTE
To change the set-up after a time-out, the following
configuration is required:
Set 0-10 Active Set-up to [9] Multi set-up and select the
relevant link in 0-12 This Set-up Linked to.
8-05 End-of-Timeout Function
Option: Function:
Select the action after receiving a valid control
word following a time-out. This parameter is
active only when 8-04 Control Timeout Function
is set to [7] Set-up 1, [8] Set-up 2, [9]Set-up 3 or
[10] Set-up 4.
[0] Hold set-up Retains the set-up selected in 8-04 Control
Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
frequency converter resumes its original set-up.
[1] Resume set- Resumes the set-up active before the time-out.
up
8-06 Reset Control Word Timeout
This parameter is active only when [0] Hold set-up has been
selected in 8-05 End-of-Timeout Function.
Option: Function:
[0] Do not reset Retains the set-up specified in 8-04 Control
Word Timeout Function, following a control
word time-out.
[1] Do reset Returns the frequency converter to the original
set-up following a control word time-out. The
frequency converter performs the reset and
then immediately reverts to the [0] Do not reset
setting
8-07 Diagnosis Trigger
This parameter has no function for DeviceNet.
Option: Function:
[0] Disable
[1] Trigger on alarms
[2] Trigger alarm/warn. This parameter has no function for
DeviceNet.
8-08 Readout Filtering
If the speed feedback value readouts on fieldbus are fluctuating,
this function is used. Select filtered if the function is required. A
power-cycle is required for changes to take effect.
Option:
[0] Motor Data Std-
Filt.
[1] Motor Data LP-
Filter
®
VLT AutomationDrive Programming Guide
Function:
Select [0] for normal bus
readouts.
Select [1] for filtered bus
readouts of the following
parameters:
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
®
MG33MG02 - VLT is a registered Danfoss trademark
8-08 Readout Filtering
If the speed feedback value readouts on fieldbus are fluctuating,
this function is used. Select filtered if the function is required. A
power-cycle is required for changes to take effect.
Option:
3.10.2 8-1* Ctrl. Word Settings
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the fieldbus installed in slot A will be visible in the LCP
display.
For guidelines in selection of [0] FC profile and [1] PROFIdrive
profile please refer to the Serial communication via RS-485
Interface section in the Design Guide.
For additional guidelines in the selection of [1] PROFIdrive profile,
please refer to the Operating Instructions for the installed
fieldbus.
Option:
[0] FC profile
*
[1] PROFIdrive profile
8-13 Configurable Status Word STW
Option: Function:
[0] No function The input is always low.
[1] Profile Default Depended on the profile set in
8-10 Control Profile.
[2] Alarm 68 Only The input goes high whenever
Alarm 68 is active and goes low
whenever no alarm 68 is actived
[3] Trip excl Alarm 68
[10] T18 DI status
[11] T19 DI status
[12] T27 DI status
[13] T29 DI status
[14] T32 DI status
[15] T33 DI status
[16] T37 DI status The input goes high whenever T37
has 0 V and goes low whenever
T37 has 24 V
[21] Thermal warning
[30] Brake fault (IGBT)
[40] Out of ref range
[41] Load throttle active
[60] Comparator 0
[61] Comparator 1
Function:
16-14 Motor current
16-16 Torque [Nm]
16-17 Speed [RPM]
16-22 Torque [%]
16-25 Torque [Nm] High
