Parameter Descriptions
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
3
3
Option:
[84]
SL digital output E
[85]
SL digital output F
[120] Local ref active
[121] Remote ref active
[122] No alarm
[123] Start command
activ
90
®
VLT
AutomationDrive Programming Guide
Function:
See 13-52 SL Controller Action. Output
E is low on Smart Logic Action [36].
Output E is high on Smart Logic
Action [42].
See 13-52 SL Controller Action. Output
F is low on Smart Logic Action [37].
Output F is high on Smart Logic
Action [43].
Output is high when 3-13 Reference
Site = [2] Local or when
3-13 Reference Site = [0] Linked to
hand auto at the same time as the
LCP is in Hand On mode.
Reference site
Local
Remote
set in
referen
reference
3-13 Reference
ce
active
Site
active
[121]
[120]
Reference site:
1
0
Local
3-13 Reference
Site [2]
Reference site:
0
1
Remote
3-13 Reference
Site [1]
Reference site:
Linked to Hand/
Auto
Hand
1
0
Hand -> off
1
0
Auto -> off
0
0
Auto
0
1
Table 3.19 Local Reference Active
Output is high when 3-13 Reference
Site = [1] Remote or [0] Linked to
hand/auto while the LCP is in Auto
On mode. See above.
Output is high when no alarm is
present.
Output is high when the Start
command high (i.e. via digital input,
bus connection or [Hand On] or
[Auto On] ), and a Stop has been last
command.
MG33MG02 - VLT
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[124] Running reverse
[125] Drive in hand mode Output is high when the frequency
[126] Drive in auto mode
[151] ATEX ETR cur. alarm Selectable if 1-90 Motor Thermal
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur.
warning
[154] ATEX ETR freq.
warning
[188] AHF Capacitor
Connect
[189] External Fan Control The internal logics for the internal
[190] Safe Function active
[191] Safe Opt. Reset req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
®
is a registered Danfoss trademark
Function:
Output is high when the frequency
converter is running counter
clockwise (the logical product of the
status bits 'running' AND 'reverse').
converter is in [Hand on] mode (as
indicated by the LED light above
[Hand on]).
Output is high when the frequency
converter is in 'Auto' mode (as
indicated by LED on above [Auto
on] ).
Protection is set to [20] or [21]. If the
alarm 164 ATEX ETR cur.lim.alarm is
active, the output will be 1.
Selectable if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR or
[21] Advanced ETR. If the alarm 166
ATEX ETR freq.lim.alarm is active, the
output will be 1.
Selectable if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR or
[21] Advanced ETR. If the alarm 163
ATEX ETR cur.lim.warning is active,
the output will be 1.
Selectable if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR or
[21] Advanced ETR. If the warning 165
ATEX ETR freq.lim.warning is active,
the output will be 1.
fan control is transferred to this
output to make it possible to control
an external fan (relevant for HP duct
cooling).
See 13-1* Comparators.
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
