This page provides you the general settings for LAN. Click LAN to open the LAN settings page
and choose General Setup.
There are several subnets provided by the router which allow users to divide groups into
different subnets (LAN1 – LAN50). In addition, different subnets can link for each other by
configuring Inter-LAN Routing. At present, LAN1 setting is fixed with NAT mode only. LAN2 –
LAN50 can be operated under NAT or Route mode. IP Routed Subnet can be operated under
Route mode.
Available settings are explained as follows:
Item
General Setup
62
e r f a c e
e r f a c e
e n e r a l S e t u p
e n e r a l S e t u p
Description
Allow to configure settings for each subnet respectively.
Index - Display all of the LAN items.
Enable - Basically, LAN1 status is enabled in default.
LAN2 –LAN50 and IP Routed Subnet can be configured after
enabling via LAN>>VLAN.
DHCP- LAN1 is configured with DHCP in default. If required,
please check the DHCP box for each LAN.
IP Address - Display the IP address for each LAN item. Such
information is set in default and you can not modify it.
Details Page - Click it to access into the setting page. Each
