Ii-5-5-2 Internal Radius - Draytek Vigor3910 Series User Manual

I I I I - - 5 5 - - 5 5 - - 2 2 I I n n
Except for being a built-in RADIUS client, Vigor router also can be operated as a RADIUS server
which performs security authentication by itself. This page is used to configure settings for
internal RADIUS server. Then users of Vigor router will be authenticated by Vigor router
directly.
Available settings are explained as follows:
Item
Enable
Authentication Port
RADIUS Client Access List
110
t t e e r r n n a a l l R R A A D D I I U U S S
Description
Select to enable the router's internal RADIUS server.
The UDP port for authentication message.
Only clients that meet the criteria configured in the access
list are allowed to access the RADIUS server.
Index - The index number of the client entry.
Enable - Select to enable this client entry.
Shared Secret - A text string that is known to both the
router's RADIUS server and the RADIUS client that is used to
Vigor3910 Series User's Guide
