I - 2 - 2 R a c k - M o u n t e d I n s t a l l a t i o n
I - 2 - 2 R a c k - M o u n t e d I n s t a l l a t i o n
The Vigor3910 Series can be mounted on the wall by using standard brackets shown below.
Attach the brackets to the chassis of a rack. The second bracket attaches the other side of the
chassis.
After the bracket installation, the Vigor3910 Series chassis can be installed in a rack by using
four screws for each side of the rack.
Desktop Type Installation
Rubber pads are included with the Vigor3910 Series. These rubber pads improve the air
circulation and decrease unnecessary rubbing on the desktop.
6 Vigor3910 Series User's Guide
