Check Enable to enable the filter rule. Type the comments (e.g., block_all). Choose

Block If No Further Match for the Filter setting. Then, click OK.

Next, set another rule. Just open Firewall>>Filter Setup. Click the Set 2 link and

choose the Filter Rule 3 button.

Check Enable to enable the filter rule. Type the comments (e.g., open_ip). Click the

Edit button for Source IP.

A dialog box will be popped up. Choose Range Address as Address Type by using the

drop down list. Type 192.168.1.10 in the field of Start IP, and type 192.168.1.20 in the

field of End IP. Then, click OK to save the settings. The computers within the range can

access into the Internet.

Vigor3910 Series User's Guide

In default, the router will check the packets starting with Set 2, Filter

Rule 2 to Filter Rule 7. If Block If No Further Match for is selected for

Filter, the firewall of the router would check the packets with the

rules starting from Rule 3 to Rule 7. The packets not matching with

the rules will be processed according to Rule 2.
