Draytek Vigor3910 Series User Manual page 159

Profile
Enable
Index
Interface
Area
MD5 Auth
Password
Key ID (1-255)
Neighborhoods
When you finish the configuration, please click OK to save and exit this page.
Vigor3910 Series User's Guide
Check it to enable and configure an OSPF profile.
1 to 8 indicates profile 1 to profile 8.
Choose a LAN / WAN interface to apply the settings
configured for this profile.
An AS will be divided into several areas. Each area must be
assigned with a dedicated number.
Enable/disable the MD5 authentication mechanism for such
profile.
Enter characters as the password for MD5 authentication.
Specify the IP address of such Vigor router.
Such ID will help Vigor router to be identified in an
autonomous system. However, if no address is specified,
then an IP address of the active interface will be used by
system automatically.
Displays current neighbors status in BGP routing
environment.
III-149
