This router allows you to create multi-PVC for different data transferring for using. Simply go
to WAN and select Multi-VLAN page.
Channel 1 to 8 have the following fixed assignments and cannot be altered.
Channels 13 through 52 can be configured as virtual WANs.
G G e e n n e e r r a a l l
The system allows you to set up to eight channels used as multi-VLAN.
Available settings are explained as follows:
Item
Channel
Enable
WAN Type
VLAN Tag
Vigor3910 Series User's Guide
u l t i - V L A N
u l t i - V L A N
Description
Display the number of each channel.
Channels
interface and can not be configured here.
Channels
Display whether the settings in this channel are enabled
(checked) or not (unchecked).
Displays the physical medium that the channel will use.
Displays the VLAN tag value that will be used for the packets
traveling on this channel.
1~8 are used by the Internet Access web user
13 ~ 52 are configurable.
