ikeid
For Dial-In Settings
itype
peer
peerid
iname
ipwd
ivj
ikey
imeth
For TCP/IP Settings
mywip
rgip
rnip
rnmask
rip
mode
droute
Vigor3910 Series User's Guide
It means IKE Local ID.
"ikeid=vigor" means Set Local ID = vigor.
It means Allowed Dial-In Type. Available settings include:
"itype=t" means PPTP.
"itype=s" means IPSec.
"itype=L1"means L2TP (None).
"itype=L1" means L2TP(Nice to Have).
"itype=l2" means L2TP(Must).
It means specify Peer VPN Server IP for Remote VPN Gateway.
Type "203.12.23.48" means to allow VPN dial-in with IP address of
203.12.23.48.
Type "off" means any remote IP is allowed to dial in.
It means the peer ID for Remote VPN Gateway.
Type "draytek" means the word is used as local ID.
It means Dial-in Username.
"iname=admin" means to set username as "admin".
It means Dial-in Password.
"ipwd=1234" means to set password as "1234".
It means VJ Compression.
"ivj=on/off" means to enable /disable VJ Compression.
It means IKE Pre-Shared Key.
"ikey=abcd" means to set IKE Pre-Shared Key = abcd.
It means IPSec Security Method
"imeth=h" means "Allow AH".
"imeth=d" means "Allow DES".
"imeth=3" means "Allow 3DES".
"imeth=a" means "Allow AES.
It means My WAN IP.
"mywip=1.2.3.4" means to set My WAN IP as "1.2.3.4".
It means Remote Gateway IP.
"rgip=1.2.3.4" means to set Remote Gateway IP as "1.2.3.4".
It means Remote Network IP.
"rnip=1.2.3.0" means to set Remote Network IP as "1.2.3.0".
It means Remote Network Mask.
"rnmask=255.255.255.0" means to set Remote Network Mask as
"255.255.255.0".
It means RIP Direction.
"rip=d" means to set RIP Direction as "Disable".
"rip=t" means to set RIP Direction as "TX".
"rip=r" means to set RIP Direction as "RX".
"rip=b" means to set RIP Direction as "Both".
It means the option of "From first subnet to remote network, you
have to do".
"mode=r" means to set Route mode.
"mode=n" means to set NAT mode.
It means to Change default route to this VPN tunnel ( Only single
