DHCP Server Options
Force router to use "DNS
Server IP address"...
Inter-LAN Routing
When you finish the configuration, please click OK to save and exit this page.
Info
I I - 3 - 1 - 1 D
I I - 3 - 1 - 1 D
There are two configuration pages for LAN1, Ethernet TCP/IP and DHCP Setup (based on IPv4)
and IPv6 Setup. Click the tab for each type and refer to the following explanations for
detailed information.
Available settings are explained as follows:
Item
Network Configuration
Vigor3910 Series User's Guide
LAN will have different LAN configuration page. Each LAN
must be configured in different subnet.
IPv6 – Click it to access into the settings page of IPv6.
DHCP packets can be processed by adding option number and
data information when such function is enabled.
For detailed information, refer to later section.
Force Vigor router to use DNS servers configured in LAN port
instead of DNS servers given by the Internet Access server
(PPPoE, PPTP, L2TP or DHCP server).
Check the box to link two or more different subnets (LAN and
LAN).
Inter-LAN Routing allows different LAN subnets to be
interconnected or isolated.
It is only available when the VLAN functionality is enabled.
Refer to section II-3-2 VLAN on how to set up VLANs.
In the Inter-LAN Routing matrix, a selected checkbox means
that the 2 intersecting LANs can communicate with each
other.
To configure a subnet, select its Detials Page button to bring up the LAN
Details Page.
e t a i l s P a g e f o r L A N
e t a i l s P a g e f o r L A N
Description
For NAT Usage,
1 E t h e r n e t T C P / I P
1 E t h e r n e t T C P / I P
–
–
a n d D H C P S e t u p
a n d D H C P S e t u p
63
