Available settings are explained as follows:
Item
Network Configuration
DHCP Server
Configuration
Vigor3910 Series User's Guide
e t a i l s P a g e f o r I P R
e t a i l s P a g e f o r I P R
Description
Enable/Disable - Click Enable to enable such configuration;
click Disable to disable such configuration.
For Routing Usage,
IP Address - This is the IP address of the router. (Default:
192.168.1.1).
Subnet Mask - The subnet mask, together with the IP Address
field, indicates the maximum number of clients allowed on
the subnet. (Default: 255.255.255.0/ 24).
RIP Protocol Control,
Enable – When Enabled, the router will attempt to exchange
routing information with neighbouring routers using the
Routing Information Protocol.
DHCP stands for Dynamic Host Configuration Protocol. The
router by factory default acts a DHCP server for your network
so it automatically dispatch related IP settings to any local
user configured as a DHCP client. It is highly recommended
that you leave the router enabled as a DHCP server if you do
not have a DHCP server for your network.
If you want to use another DHCP server in the network other
than the Vigor Router's, you can let Relay Agent help you to
redirect the DHCP request to the specified location.
Start IP Address - Enter a value of the IP address pool for the
DHCP server to start with when issuing IP addresses. If the
1st IP address of your router is 192.168.1.1, the starting IP
address must be 192.168.1.2 or greater, but smaller than
192.168.1.254.
IP Pool Counts - Enter the maximum number of PCs that you
