as <value>
hold <value>
retry <value>
id <value>
show
neighbor <idx> mode <0/1>
neighbor <idx> name <max
len: 20>
neighbor <idx> ip <x.x.x.x>
neighbor <idx> as
<1~4294967295>
neighbor <idx> md5 <0/1>
neighbor <idx> key <max
len: 20>
neighbor <idx> show
neighbor show all
static <sidx> <ip> <netmask>
static <sidx> delete
static show
E x a m p l
E x a m p
> ip bgp static 1 192.168.2.56 255.255.255.0
Set static network index: 1
Vigor3910 Series User's Guide
It means to set the AS number for local router.
<value>: Available number is between 0 and 4294967295.
It means to set the time interval to determine the peer is dead
when the router is unable to receive any keepalive message from
the peer within the time.
<value>: Available number is between 10 and 65535 (unit: second).
The default is 180 (seconds).
It means to set a period of time to reconnect if the router fails to
connect to the neighboring router.
<value>: Available number is between 3 and 255 (unit: second). The
default is 120 (seconds).
It means to specify the LAN subnet <1~16> as router ID.
<value>: Available number is between 1 and 16.
It means to display information related to BGP settings.
It means to enable / disable the basic BGP function for neighboring
router.
<idx>: Available profile number is between 1 and 8.
<0/1>: 0- disable; 1- enable
It means to define a profile name for neighboring router.
<idx>: Available profile number is between 1 and 8.
<max len>: The maximum name length shall not be over 20
characters.
It means to set the IP address specified for the neighboring router.
<idx>: Available profile number is between 1 and 8.
<x.x.x.x>: Enter the IP address, e.g., 100.100.100.100.
It means to set the AS number for the neightboring router.
<idx>: Available profile number is between 1 and 8.
<value>: Available number is between 1 and 4294967295.
It means to enable or disable (1/0) for MD5 function for the
neightboring router.
It menas to define a key for the neightboring router.
<max len>: The maximum name length shall not be over 20
characters.
It means to display information for the specified profile.
<idx>: Available profile number is between 1 and 8.
It means to display information for all neighboring routers.
It means to configure the neighboring router(s) for exchanging the
routing information with the local router.
<sidx>: Available profile number is between 1 and 16.
<ip>: Enter the IP address, e.g., 100.100.100.200.
<netmask>: Enter the subnet mask for the neighboring router, e.g.,
255.255.255.0.
It means to delete static network settings for neighboring router.
<sidx>: Available profile number is between 1 and 16.
It means to display setting information for exchanging the routing
information with the local router.
e
l e
