Port Setup - Draytek Vigor3910 Series User Manual

I I - 1 P o r t S e t u
I I - 1 P o r t S e t u
This page is used for configuring tranmission rate for LAN and WAN ports respectively.
Due to hardware restriction, the speed of P3 is the same as the speed of P4. So whenever P3 is
changed, P4 is changed too and vice versa.
Available settings are explained as follows:
Item
Port
Function
Speed
32
p
p
Description
Display the physical ports on Vigor router.
P1 ~ P8 - These ports are switchable between WAN and LAN
ports.
P1 ~ P2 - Available options include Auto, 10G and 1G.
P3 ~ P4 - Available options include Auto and 2.5G. Due to the
hardware limitation, the speed for P4 is the same as P3.
P5 ~ P12- Available options include Auto, 1G, 100M, and 10
M.
