Draytek Vigor3910 Series User Manual page 182

Available settings are explained as follows:
Item
Set to Factory Default
View
Index
Enable
Name
Remote Network
Status
Pass Routing LAN to VPN
Pass Packets to NAT when
VPN disconnects
Backup
Restore
To edit each profile:
1. Click each index to edit each profile and you will get the following page. Each
LAN-to-LAN profile includes 5 subgroups. If the fields gray out, it means you may leave it
untouched. The following explanations will guide you to fill all the necessary fields.
172
Description
Click to clear all indexes.
All – Shows all LAN-to-LAN VPN profiles.
Trunk – Shows all Trunk profiles (see VPN and Remote Access
>> VPN TRUNK Management).
Click the index number of the profile to view or edit its
settings.
Check to enable the LAN-to-LAN VPN profile.
Display the name of the LAN-to-LAN profile. The symbol ???
represents that the profile is empty.
Display the name of the remote network.
Shows the status of the profile.
Online – LAN-to-LAN VPN is connected.
Offline – LAN-to-LAN VPN is disconnected.
--- – Profile is disabled.
Check the box to allow the packets from the Routing LAN to
pass over the VPN tunnel.
Default setting is "Disable".
If enabled, the Vigor router will send the packets to the
default gateway once the VPN disconnects.
Default setting is "Enable".
Click Backup to save the configuration.
Click Select to choose a configuration file. Then click
Restore to apply the file.
Vigor3910 Series User's Guide
