Comment
Time
Frequency
You can set up to 15 schedules. Then you can apply them to your Internet Access or VPN and
Remote Access >> LAN-to-LAN settings.
To add a schedule:
1. Click any index, say Index No. 1.
2. The detailed settings of the call schedule with index 1 are shown below.
Available settings are explained as follows:
Item
Enable Schedule
Setup
Comment
Start Date
(yyyy-mm-dd)
Start Time (hh:mm)
Duration Time
(hh:mm)
End Time (hh:mm)
Action
106
Display the name of the time schedule.
Display the valid time period by time bar.
Display which day(s) will be always on and which day(s) will
be always off of the schedule profile by color boxes.
- If it lights in green, it means such schedule is active.
Description
Check to enable the schedule.
Type a short description for such schedule.
Specify the starting date of the schedule.
Specify the starting time of the schedule.
Specify the duration (or period) for the schedule.
It will be calculated automatically when Start Time and
Duration Time are configured well.
Specify which action Call Schedule should apply during the
period of the schedule.
Force On -Force the connection to be always on.
Force Down -Force the connection to be always down.
