Draytek Vigor3910 Series User Manual page 95

Available settings are explained as follows:
Item
Private IP
Choose IP
DMZ Host for other WAN interface is slightly different with WAN1. Active True IP selection is
available for WAN1 only.
See the following figure.
If you previously have set up WAN Alias for PPPoE or Static or Dynamic IP mode in WAN2
interface, you will find them in Aux. WAN IP for your selection.
Vigor3910 Series User's Guide
Description
Choose Private IP or None first.
Enter the private IP address of the DMZ host, or click Choose
PC to select one.
Click this button and then a window will automatically pop
up, as depicted below. The window consists of a list of private
IP addresses of all hosts in your LAN network. Select one
private IP address in the list to be the DMZ host.
When you have selected one private IP from the above dialog,
the IP address will be shown on the screen. Click OK to save
the setting.
85
