Draytek Vigor3910 Series User Manual page 369

Quota Policy Profile
Web Portal Options
HTTPS Redirection
Captive Portal
Detection
Landing Page After Authentication
Fixed URL
User Requested URL
Bulletin Message
Force Landing Page
Stay
Applied Interfaces
Subnet
Finish
Cancel
Vigor3910 Series User's Guide
Choose a policy profile to apply to web portal clients.
If this option is selected, unauthenticated clients accessing HTTPS
websites will be redirected to the login page, but the browser may
alert the user of certificate errors. If this option is not selected,
attempts to access to HTTPS website will time out without
redirection.
If this option is selected, the web portal page is triggered
automatically when an unauthenticated client tries to access the
Internet. This function is not available when the Login Mode is
Social Login, as the web portal page may not be shown correctly
due to the limitations of the operating system's built-in Captive
Portal Detection.
Specifies the webpage that will be displayed after the user has
successfully authenticated.
The user will be redirected to the specified URL. This could be used
for displaying advertisements to users, such as guests requesting
wireless Internet access in a hotel.
The user will be redirected to the URL they initially requested.
The message configured here will be briefly shown for a few
seconds to the user.
Default Message – This button is enabled when Bulletin Message is
selected. Click to load the default text into the bulletin message
textbox.
This option is useful for mobile phone user.
The mobile phone users can access into Internet by means of Wi-Fi
connection. In general, when Captive Portal Detection is enabled
on Vigor router, the login page will appear once the mobile phone
detects the Wi-Fi signal. After entering the username and password
(for authentication), the landing page will appear first on the
screen of the mobile phone.
Yet, some mobile phone will skip the landing page and access the
Internet instead. This feature can force the landing page to stay on
the screen of the mobile phone for a while.
Enable - Select it to enter the period of time for keeping the
landing page.
The current Hotspot Web Portal profile will be in effect for the
selected subnets.
Click to complete the configuration.
Click to abort the configuration process and return to the profile
summary page.
359
