Draytek Vigor3910 Series User Manual page 618

E x a m p l
E x a m p
> wan lb status
WAN1: on
WAN2: on
WAN3: on
WAN4: on
WAN5: on
WAN6: on
WAN7: on
T e l n e t C o m m
T e l n e t C o m m
This command allows you to configure multi-VLAN for WAN and LAN. It supports pure bridge
mode (modem mode) between Ethernet WAN and LAN port 2~4.
S S y y n n t t a a x x
wan mvlan [pvc_no/status/save/enable/disable] [on/off/clear/tag tag_no] [service
type/vlan priority] [px ... ][ Keep Tag]
S y n t a x
S y n t a x
Parameter
pvc_no
status
save
enable/disable
on/off
clear
tag tag_no
service type
vlan priority
px
Keep Tag
E E x x a a m m p p l
PVC 7 will map to LAN port 2/3/4 in bridge mode; service type is Normal. No tag added.
> > wan mvlan 7 on p2 p3 p4
PVC Bridge p1 p2 p3 p4 p5 p6
------------------------------------------------------------------
7 ON
608
e
l e
a n d : w a n m v l a n
a n d : w a n m v l a n
D e s c r i p t i o n
D e s c r i p t i o n
Description
It means index number of PVC. There are 10 PVC, 0(Channel-1) to
9(Channel-9) allowed to be configured.
However, only 2 to 9 are available for configuration.
It means to display the whole Bridge status.
It means to save the configuration into flash of Vigor router.
It means to enable/disable the Multi-VLAN function.
It means to turn on/off bridge mode for the specific channel.
It means to turn off/clear the port.
It means to tag a number for the VLAN.
-1: No need to add tag number.
1-4095: Available setting numbers used as tagged number.
It means to specify the service type for VLAN.
0: Normal.
1: IGMP.
It means to specify the priority for the VALN setting.
Range is from 0 to 7.
It means LAN port. Available setting number is from 2 to 4. Port
number 1 is locked for NAT usage.
It means Multi-VLAN packets will keep their VLAN headers to LAN.
l e e
0 0 1 1 0 0
Service Type Tag
Normal 0(OFF)
Priority Keep Tag
0 OFF
