Authentication
User Profile
To add a User Profile to the RADIUS server, select it under Available List, then click the
button. To remove a User Profile from the RADIUS server, select it under Selected
Authentication List, then click the
To save changes on the page, click OK. To discard changes, click Cancel. To reset all settings
to blank, click Clear.
Vigor3910 Series User's Guide
authenticate messages sent between them. Maximum length
is 36 characters.
IP Address – Enter the base address of the IP block.
IP Mask – Enter the IP mask to configure the size of the IP
block.
IPv6 Address –Enter the base address of the IPv6 block.
IPv6 Length - Enter the prefix length of the IPv6 block.
Select the authentication protocol(s) to be used.
PAP Only – Only the Password Authentication Protocol will be
used to validate users.
PAP/CHAP/MS-CHAP/MS-CHAPv2 – PAP, CHAP
(Challenge-Handshake Authentication Protocol), and
Microsoft versions of CHAP can be used to validate users.
During the process of security authentication, user account
and user password will be required for identity
authentication. Before configuring such page, create at least
one user profile in User Management>>User Profile first.
Select All – Click to move all user profiles under the
Available List to the Authentication List.
Clear All- Click to remove all user profiles from the
Authentication List.
Available List – User profiles (created in User Management
>> User Profile) that have not been added to the
authentication list.
Authentication List – User profiles (created in User
Management >> User Profile) that have been added to the
authentication list. Users can log in using these profiles.
button.
