1. Go to LAN page and click General Setup, select 1st Subnet as the RIP Protocol Control.
Then click the OK button.
Info
2. Click the LAN >> Static Route and click on the Index Number 1. Check the Enable box.
Please add a static route as shown below, which regulates all packets destined to
192.168.10.0 will be forwarded to 192.168.1.2. Click OK.
Available settings are explained as follows:
Item
Enable
Destination IP
Address
Subnet Mask
Gateway IP Address
Network Interface
3. Return to Static Route Setup page. Click on another Index Number to add another
static route as show below, which regulates all packets destined to 211.100.88.0 will be
forwarded to 192.168.1.3. Click OK.
138
There are two reasons that we have to apply RIP Protocol Control on
1st Subnet. The first is that the LAN interface can exchange RIP
packets with the neighboring routers via the 1st subnet
(192.168.1.0/24). The second is that those hosts on the internal
private subnets (ex. 192.168.10.0/24) can access the Internet via the
router, and continuously exchange of IP routing information with
different subnets.
Description
Click it to enable this profile.
Type an IP address as the destination of such static route.
Type the subnet mask for such static route.
Type the gateway IP addres for such static route.
Use the drop down list to specify an interface for such
static route.
