Status Reporting

Overload Event Register (:OVLRegister)

The Overload Event Register register hosts these bits:
Name
Channel 1 OVL
Channel 2 OVL
Channel 3 OVL
Channel 4 OVL
External Trigger
OVL
Channel 1 Fault
Channel 2 Fault
Channel 3 Fault
Channel 4 Fault
External Trigger
Fault
1410
Location Description
bit 0 Overload has occurred on Channel 1 input.
bit 1 Overload has occurred on Channel 2 input.
bit 2 Overload has occurred on Channel 3 input.
bit 3 Overload has occurred on Channel 4 input.
bit 4 Overload has occurred on External Trigger input.
bit 6 Fault has occurred on Channel 1 input.
bit 7 Fault has occurred on Channel 2 input.
bit 8 Fault has occurred on Channel 3 input.
bit 9 Fault has occurred on Channel 4 input.
bit 10 Fault has occurred on External Trigger input.
