CIP Objects
12.12

ADI Object (A2h)

Category
Extended
Object Description
This object maps instances in the Application Data Object to EtherNet/IP. All requests to this object will be
translated into explicit object requests towards the Application Data Object in the host application; the
response is then translated back to CIP-format and sent to the originator of the request.
The ADI Object can be disabled using attribute 30 in the EtherNet/IP Host Object (F8h). This attribute can also
be used to change the ADI Object number.
See also ..
• Application Data Object (see Anybus CompactCom 40 Software Design Guide)
• Parameter Object (0Fh), p. 109
• EtherNet/IP Host Object (F8h), p. 200
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max Instance Get
3 Get
Number of
instances
For information about the Application Data Object, please consult the Anybus CompactCom 40 Software
Design Guide.
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
(CIP Object)
Get_Attribute_Single
Get_Attribute_Single
Set_Attribute_Single
Type
Value
UINT
0002h (Object revision)
UINT Equals attribute #4 in the Application Data Object
UINT
Equals attribute #3 in the Application Data Object
