Web Server
Interface Counters
Out Ucast packets:
Out NUcast packets:
Out Discards:
Out Errors:
Media Counters
Alignment Errors
FCS Errors
Single Collisions
Multiple Collisions
SQE Test Errors
Deferred Transmissions
Late Collisions
Excessive Collisions
MAC Receive Errors
MAC Transmit Errors
Carrier Sense Errors
Frame Size Too Long
Frame Size Too Short
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Description
Sent unicast packets.
Sent non unicast packets (broadcast and multicast).
Outgoing packets discarded due to no available memory buffers.
Transmission errors.
Description
Frames received that are not an integral number of octets in length.
Frames received that do not pass the FCS check.
Successfully transmitted frames which experienced exactly one collision.
Successfully transmitted frames which experienced more than one collision.
Number of times SQE test error messages are generated.
(Not provided with current PHY interface.)
Frames for which first transmission attempt is delayed because the medium is
busy.
Number of times a collision is detected later than 512 bit-times into the
transmission of a packet.
Frames for which a transmission fails due to excessive collisions.
Frames for which reception of an interface fails due to an internal MAC sublayer
receive error.
Frames for which transmission fails due to an internal MAC sublayer receive
error.
Times that the carrier sense condition was lost or never asserted when
attempted to transmit a frame.
Frames received that exceed the maximum permitted frame size.
Frames received that are shorter than lowest permitted frame size.
