Anybus Module Objects
Instance Attributes (Instance #8 Ethernet Communication Settings 2)
Changes have immediate effect.
# Name
1 Name
2 Data type
3
Number of elements
4 Descriptor
5 Value
6
Configured Value
Instance Attributes (Instance #9, DNS1)
This instance holds the address to the primary DNS server. Changes are valid after reset.
# Name
1 Name
2 Data type
3
Number of elements
4 Descriptor
5
Value
6
Configured Value
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Description
Get
Array of CHAR "Comm 2"
(Multilingual, see page 145)
Get UINT8
08h (= ENUM)
Get UINT8
01h (one element)
Get UINT8
07h (read/write/shared access)
ENUM Value
Get/Set
00h
01h
02h
03h
04h
Get ENUM
Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Value
00h
01h
02h
03h
04h
Access Data Type
Description
Get Array of CHAR "DNS1"
(Multilingual, see page 145)
Get UINT8 04h (= UINT8)
Get UINT8
04h (four elements)
Get UINT8
07h (read/write/shared access)
Array of UINT8 If read, the actual value will be received. If written, the written value
Get/Set
is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get
Array of UINT8 Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
String Meaning
(Multilingual, see page 145)
"Auto" Auto negotiation (default)
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
String Meaning
(Multilingual, see page 145)
Auto negotiation
"Auto"
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
