8.12 ADI Object (A2h)

Category
Extended
Object Description
This object maps instances in the Application Data Object to EtherNet/IP. All requests to this object
will be translated into explicit object requests towards the Application Data Object in the host applica-
tion; the response is then translated back to CIP-format and sent to the originator of the request.
The ADI Object can be disabled using attribute 30 in the EtherNet/IP Host Object (F8h). This attribute
can also be used to change the ADI Object number.
See also...
• Application Data Object (see Anybus CompactCom 40 Software Design Guide)
• "Parameter Object (0Fh)" on page 74 (CIP Object)
• "EtherNet/IP Host Object (F8h)" on page 161
Supported Services
Class:
Instance:
Class Attributes
# Name
1 Revision
2 Max Instance
3 Number of instances
a. Consult the general Anybus CompactCom 40 Software Design Guide for further information.
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Get_Attribute_Single
Get_Attribute_Single
Set_Attribute_Single
Access Type
Get UINT
Get UINT
Get UINT
Value
Object revision (Current value = 0002h)
Equals attribute #4 in the Application Data Object
Equals attribute #3 in the Application Data Object
