Anybus Module Objects
Instance Attributes (Instance #20, QuickConnect)
This instance enables or disables the QuickConnect functionality from the application. Changes are valid after
reset or power cycle. The value of the QuickConnect attribute (#12) in the TCP/IP Interface object (F5h), will
change immediately.
This instance has no effect unless QuickConnect is enabled in the EtherNet/IP host object. If QuickConnect is
disabled in the EtherNet/IP host object the application is advised to hide this instance to the end-user.
See also...
• TCP/IP Interface Object (F5h), p. 122
• EtherNet/IP Host Object (F8h), p. 200
# Name
1 Name
2 Data type
3
Number of elements
4 Descriptor
5 Value
6
Configured Value
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Description
Get
Array of CHAR "QuickConnect"
Get UINT8 08h (= ENUM)
Get UINT8
01h (one element)
Get UINT8
07h (read/write/shared access)
ENUM If read, the actual value will be received. If written, the written value is
Get/Set
reflected in attribute #6 until a reset.
Value:
00h
01h
Get ENUM
Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Value:
00h
01h
Meaning:
Disable (default)
Enable
Meaning:
Disable
Enable
