Anybus CompactCom 40 Network Manual page 119

CIP Objects
Instance Attributes
# Name Access
1 Power Get
Management
Command
2 Power Get
Management
Status
3 Get
Client Path
4 Get
Number of
Power
Management
Modes
5 Power Get
Management
Nodes
6 Sleeping State Get
Support
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Type
Value/Description
DWORD
Collection of bit fields comprising the most recent power management request.
DWORD Collection of bit fields providing Power Management status information.
Struct of: Specifies the EPATH from this instance (server) to its current owner (client).
UINT (Path Size) Size of path (in words
Padded EPATH
(Path)
UINT
Number of Power Management Mode array entries in attribute 5.
Array of: Array of low power modes
Struct of: Modes (Array of mode structures)
USINT
Minimum Pause Units (Specifies the unit of Minimum Pause Time)
UINT Minimum Pause Time
USINT
Resume Units (Specifies the unit of Resume Time)
UINT
Resume Time (Required time to transition from the paused stated to the
owned state.
REAL
Power Level (Power in kW for this mode)
BOOL
Availability (Specifies whether this mode can be entered given the current
device state)
BOOL
0 (Sleeping state not supported)
117 (244)
SCM-1202–069 1.9 en-US
