Host Application Objects
Command Details: Process_CIP_Object_Request
Category
Extended
Details
Command Code:
Valid for:
Description
By setting the 'Enable CIP Request Forwarding'-attribute (#11), all requests to unimplemented CIP-objects and
unknown assembly object instances, will be forwarded to the host application through this command. The
application then has to evaluate the request and return a proper response. The module supports one CIP-
request; additional requests will be rejected by the module.
Note that since the telegram length on the host interface is limited, the request data size must not exceed 255
bytes. If it does, the module will send a 'resource unavailable' response to the originator of the request and
the message will not be forwarded to the host application.
This command is similar - but not identical - to the 'Process_CIP_Request'-command in the Anybus
CompactCom 40 DeviceNet.
• Command Details
Field Contents
CmdExt[0] CIP Service Code
CmdExt[1] Request Path Size
MsgData[0... m] Request Path
Request Data
MsgData[m... n]
• Response Details
Contents
Field
CmdExt[0] CIP Service Code
CmdExt[1] 00h
MsgData[0] General Status
MsgData[1] Size of Additional Status
MsgData[2... m] Additional Status
MsgData[m... n] Response data
When using this functionality, make sure to implement the common CIP Class Attribute (attribute #1,
Revision) for all objects in the host application firmware. Failure to observe this will prevent the module
from successfully passing conformance tests.
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
10h
Object
Comments
CIP service code from original CIP request
Number of 16-bit words in the Request Path field
CIP EPATH (Class, Instance, Attr. etc.)
Service-specific data
Comments
(Reply bit set)
(reserved, set to zero)
CIP General Status Code
Number of 16-bit words in Additional Status array
Additional Status, if applicable
Actual response data, if applicable
