OPC UA
10.3.1 Identification Parameters
A number of identification parameters are presented on OPC UA by the Server Object and by the
Device Instance of the OPC UA Device Integration model. Some parameters are only used in
either the Server Object or the Device Object while some are used in both objects. This chapter
specifies the sources of each parameter and what parameters in the Server Object or the Device
Object that are equal.
Parameter
Product URI
Manufacturer name
Manufacturer
Product name
Application name
Software version
Software revision
Build number
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
DataType
Used by/in
Server object/Server String
Status/BuildInfo
ApplicationDescription
String
Server object/Server
Status/BuildInfo
DeviceType LocalizedText
String
Server object/Server
Status/BuildInfo
ApplicationDescription LocalizedText
String
Server object/Server
Status/BuildInfo
Property of the device
instance
String
Server object/Server
Status/BuildInfo
Source/Default
Can be configured in the OPC UA Host Object
(E3h).
Default value = "http://hms-networks.com/UA/
Anybus/CompactCom40/[networktype]/
[softwareversion]"
[networktype] = Abbreviation of network
[softwareversion] = Shall equal SoftwareVersion
of this table
Equals the manufacturer name of the Anybus
CompactCom. The name is provided by the
Anybus CompactCom following the priority
specified for the Application Object (FFh),
instance attribute #8 (Vendor Name).
The user (the host application) can configure
the manufacturer name in the host object of
the industrial network (if applicable) or in the
application host object.
Equals the product name of the Anybus
CompactCom. The name is provided by the
Anybus CompactCom following the priority
specified for the Application Object (FFh),
instance attribute #9 (Product Name).
Equals the software version of the Anybus
CompactCom as a string. The software version is
provided by the Anybus CompactCom following
the priority specified for Application Object
(FFh), instance attribute #10 (Firmware version).
In case the software version isn't already in
string format it is converted by the Anybus
CompactCom to string format X.YY where X is
major version and YY is minor version.
Equals the build number of the Anybus
CompactCom.
The build number is provided by the Anybus
CompactCom according to the following:
1. If a network host object is implemented,
the build number specified here is used. If
the network host object is implemented,
but no build number is available for the
firmware version, the build number will
default to 1.
2. If network host object isn't implemented,
but the Application Object (FFh), attribute
#10 (Firmware version) is, the build
number in this attribute will be used.
3. Anybus CompactCom default value will be
used.
