CIP Objects
Instance Attributes
Attributes #1–4 and #6–7 an be customized by implementing the EtherNet/IP Host Object, see
Host Object (F8h), p. 200
# Name Access
1 Get
Energy/
Resource Type
2 Base Energy Get
Object
Capabilities
Get
3 Energy
Accuracy
4 Energy Get
Accuracy Basis
7 Get
Consumed
Energy
Odometer
8 Get
Generated
Energy
Odometer
12 Energy Type Get
Specific Object
Path
• Depending on whether the instance reports consumed or generated energy, either attribute #7 or
attribute #8 is required.
• The struct data type ODOMETER makes it possible to represent very large values, for more information
please consult the CIP specification Volume 1 (CIP Common).
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Type
Value/Description
UINT Type of energy managed by this instance
Always 0 (Generic)
UINT Always 0 (Energy measured)
UINT
Specifies the accuracy of power and energy metering results, either in 0.01
percent of reading (default) or 0.01 of other units specified in attribute #4. If 0,
unknown.
UINT Always 0 (Percent of reading)
ODOMETER
The value of the consumed energy.
ODOMETER
The value of the generated energy.
Struct of: NULL path
UINT (Path size)
padded EPATH
(Path)
