Anybus CompactCom 40 Network Manual page 204

Host Application Objects
# Name
17
Enable unconnected
routing
18
Input-Only extended
heartbeat instance
number
19
Listen-Only extended
heartbeat instance
number
20 Interface label port 1
21 Interface label port 2
22 Interface label internal
port
23 -
(reserved)
25
26
Enable EtherNet/IP
QuickConnect
27 - (reserved)
28
29 Ignore Sequence Count
Check
30
ABCC ADI Object
Number
31 Enable DLR
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Default
Value
Get BOOL False
Get UINT16
0006h
Get UINT16
0007h
Get Array of CHAR Port 1
Get Array of CHAR Port 2
Get Array of CHAR Internal
Get BOOL
False
Get BOOL False
Get UINT16
00A2h
Get BOOL True
Comment
If true, the module enables unconnected CIP routing. This
also triggers an initial upload of the contents of the CIP Port
Mapping object.
See "Instance 06h Attributes (Heartbeat, Input-Only
Extended)" in Assembly Object (04h), p. 102
See "Instance 06h Attributes (Heartbeat, Listen-Only
Extended)" in Assembly Object (04h), p. 102
The value of this attribute is used to change the interface
label for Ethernet Link Object Instance #1
The value of this attribute is used to change the interface
label for Ethernet Link Object Instance #2
The value of this attribute is used to change the interface
label for Ethernet Link Object Instance #3
Meaning
Value
True
EtherNet/IP QuickConnect functionality
enabled.
False False EtherNet/IP QuickConnect functionality
disabled.
If the module is configured to use EIP QuickConnect
functionality, the EDS file has to be changed. As the EDS file
is changed, the identity of the module has to be changed
and the module will require certification.
Setting this attribute to "true" makes the module ignore the
Sequence Count Check for consumed Class 1 data. This
means that all data, not just changed/new data, received
from the Originator, will be copied to the application.
Copying all data and not just changed data is a violation of
the CIP specification. It will also affect the performance of
the module.
Use precaution when setting this flag to"true".
HMS Industrial Networks will do NO performance
measurements and states NO guarantees about how
performance will be affected when copying all data.
This attribute either changes the object number of theADI
Object (CIP object) or disables the ADI Object (CIP object).
Valid object numbers are within the vendor specific ranges
(0064h - 00C7h and 0300h - 04FFh). Any other value will
disable the ADI object.
Value Meaning
True
DLR functionality enabled
False DLR functionality disabled
202 (244)
(CIP-object).
(CIP-object).
SCM-1202–069 1.9 en-US
