  • Page 1 ® Anybus CompactCom Starter Kit REFERENCE GUIDE HMSI-27-224 2.0 ENGLISH...
  • Page 2 HMS Industrial Networks AB has intellectual property rights relating to technology embodied in the product de- scribed in this document. These intellectual property rights may include patents and pending patent applications in the USA and other countries. ® Anybus CompactCom Starter Kit Reference Guide HMSI-27-224 2.0...

  • Page 3: Table Of Contents

    Expansion Board Overview...................10 Option Board Overview (Brick) ..................12 Software........................... 18 General........................18 Transport Provider .......................18 Host Application Example Code ..................18 A Technical Specification ....................19 Power Supply ......................19 Environmental Specification..................19 EMC Compliance......................19 ® Anybus CompactCom Starter Kit Reference Guide HMSI-27-224 2.0...
  • Page 4 This page intentionally left blank...

  • Page 5: Preface

    Preface About this Document This document is intended to provide a good understanding of how to install the Anybus Com- pactCom Starter Kit. It does not cover any of the network specific features offered by the Any- bus CompactCom products; this information is available in the appropriate Network Guide.

  • Page 6: Document Conventions

    The terms “Anybus” or “module” refers to the Anybus CompactCom module. • The terms “host” or “host application” refer to the device that hosts the Anybus. • Hexadecimal values are written in the format NNNNh or 0xNNNN, where NNNN is the hex- adecimal value.

  • Page 7: Trademark Information

    Signals which are “tied to 3V3” are directly connected to 3V3. Trademark Information Anybus ® is a registered trademark of HMS Industrial Networks AB. All other trademarks are the property of their respective holders. ® Anybus CompactCom Starter Kit Reference Guide HMSI-27-224 2.0...

  • Page 8: General Information

    General Information 6 (20) General Information The Anybus CompactCom Starter Kit is a development kit for the Anybus CompactCom plat- form (chip, brick and module), which gives designers instant access to the capabilities of the Anybus CompactCom range of products.

  • Page 9: Description

    The starter kit package includes a development board, which can be used to develop network- ing applications via the host interface channels of the Anybus CompactCom module. Depend- ing on selected starter kit , the kit includes either an option board for Anybus CompactCom M40/M30 (module) or Anybus CompactCom B40 (brick).
  • Page 10 Description 8 (20) 3.2.1 Connectors Fig. 2 Description Power switch Power connector (24 V) 24 V RS232 connector USB2 connector ® Anybus CompactCom Starter Kit Reference Guide HMSI-27-224 2.0...
  • Page 11 Control Switch Leave all switches in off position for normal operation. Power to the Anybus CompactCom module. If this switch is on, the module is pow- ered, whether or not the PC has established a path to the module. On: Reset release for the Anybus CompactCom module, overriding software reset.

  • Page 12: Expansion Board Overview

    Expansion Board Overview The Anybus CompactCom Expansion Board is plugged into the host application connector of the development board and provides in-circuit access to all signals of the Anybus CompactCom host interface, allowing in-circuit debugging and evaluation capacities. Any Anybus Compact- Com , with or without housing, can be connected to this board.
  • Page 13 Description 11 (20) 3.3.1 Host Interface Signals The Anybus CompactCom host interface signals are available through six 16-pin headers (2.54 mm). • The upper row of each header is connected to signal ground. • The lower row of each header holds the host interface signals.

  • Page 14: Option Board Overview (Brick)

    Please refer to the Anybus CompactCom M40/M30 Hardware Design Guide for more information. Option Board Overview (Brick) The option board for brick provides in-circuit access to all signals of the Anybus CompactCom host interface, allowing in-circuit debugging and evaluation capacities. The option board operates at 3.3 VDC.
  • Page 15 Host application interface of brick Network interface of brick Network interface of connector board JP17 - JP22 Headers providing access to Anybus CompactCom host interface signals, see Host In- terface Signals, p. 16 JP24 Power Source Selection (JP24), p. 15 JP25 External Power Connector (JP25), p.
  • Page 16 The board has no on board power regulation, i.e. it is required to use a regulated 3.3 VDC power source as specified by the Anybus CompactCom M40/M30 Hardware Design Guide. Exceeding the specified voltage WILL cause irreparable damage to the Anybus CompactCom and/or the host application. ® Anybus CompactCom Starter Kit Reference Guide HMSI-27-224 2.0...
  • Page 17 The power for the expansion board can be supplied either from the development board connec- tor (1) or from an external power source (4). Jumper Location Power Source Internal (via developmnet board connector) External (via external power connector) ® Anybus CompactCom Starter Kit Reference Guide HMSI-27-224 2.0...
  • Page 18 Description 16 (20) 3.4.3 Host Interface Signals The Anybus CompactCom host interface signals are available through six 16-pin headers (2.54 mm). • The lower row of each header is connected to signal ground. • The upper row of each header holds the host interface signals.
  • Page 19 Signals TxD and RxD (JP22) are printed on the board as seen from the application. The signal names for the different modes are given as seen from the brick. Please refer to the Anybus CompactCom B40 Hardware Design Guide for more information. ®...

  • Page 20: Software

    Software 18 (20) Software General The software described below, is part of the Anybus CompactCom Starter Kit and is available at www.anybus.com/starterkit40. Transport Provider The Transport Provider is a set of drivers that allows a PC with Microsoft Windows ™...

  • Page 21: A Technical Specification

    Maximum power consumption is 300 mA @ 24 V DC. Typical power consumption: 150 mA @ 24 V DC Environmental Specification Consult the Anybus CompactCom Hardware Design Guide for further information. EMC Compliance Consult the Anybus CompactCom Hardware Design Guide for further information.
