Anybus Module Objects
Instance Attributes (Instance #6, DHCP Enable)
Value is used after module reset.
# Name
1 Name
2 Data type
3
Number of elements
4 Descriptor
5 Value
6
Configured Value
Instance Attributes (Instance #7 Ethernet Communication Settings 1)
Changes have immediate effect.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5
Value
6
Configured Value
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Description
Get
Array of CHAR "DHCP"
(Multilingual, see page 145)
Get UINT8
08h (= ENUM)
Get UINT8
01h (one element)
Get UINT8
07h (read/write/shared access)
ENUM If read, the actual value will be received. If written, the written value
Get/Set
is reflected in attribute #6 until a reset.
(Multilingual, see page 145)
Value
00h
01h
Get ENUM
Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Value
00h
01h
Access Data Type
Description
Get
Array of CHAR "Comm 1"
(Multilingual, see page 145)
Get UINT8
08h (= ENUM)
Get UINT8
01h (one element)
Get UINT8
07h (read/write/shared access)
ENUM
Get/Set Value
00h
01h
02h
03h
04h
Get ENUM
Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Value
00h
01h
02h
03h
04h
String Meaning
"Disable" DHCP disabled
"Enable" DHCP enabled (default)
String Meaning
"Disable" DHCP disabled
"Enable" DHCP enabled
String Meaning
(Multilingual, see page 145)
"Auto" Auto negotiation (default)
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
String Meaning
(Multilingual, see page 145)
"Auto" Auto negotiation
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
