OPC UA
10.2.1 Local Server namespace
The local server namespace contains all object and variable instances implemented by the
Anybus CompactCom. The Anybus CompactCom models nodes representing the Application Data
Instances (ADIs) and nodes representing the device in this namespace.
Node ID Range
0x01000000-0x01FFFFFF
0x02000100-0x020001FF
10.2.2 Anybus CompactCom 40 namespace
The Anybus CompactCom 40 namespace contains all types defined by HMS Industrial Networks
for the CompactCom 40 device model. It is possible to change the URI from the host application.
At the moment there is one type of node in the Anybus CompactCom 40 namespace:
Node ID
type
Numeric
10.3

CompactCom 40 Device Type

The CompactCom40DeviceType is a subtype of the DeviceType of the OPC Foundation's Device
Integration (OPC UA DI) model. The CompactCom40 instance of this subtype, is placed in the
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Description
NodeId range reserved for nodes related to ADIs.
The node IDs in this range shall have the following encoding: 0x01MMMMNN
• MMMM = ADI number
• NN = A node of an ADI
This encoding allows every ADI to have up to 256 different nodes in the OPC UA address
space. Several node IDs are needed per ADI to present the ADI value, default/max/min
value of the ADI etc.
NN: Description
0x00:
Value variable nodes of the ADIs
0x01:
Max value variable nodes of the ADIs
0x02:
Min value variable nodes of the ADIs
0x03: Default value variable nodes of the ADIs
0x04: OptionSetValues property of OptionSetType (variable type of ADI BITS and
BIT data types)
0x05:
EnumStrings property of MultiStateDiscreteType (variable type of ADI
ENUM data type)
NodeId range reserved for the device.
The node IDs of this range shall have the following encoding: 0x020001NN, where NN is
a node of a device.
The following nodes are defined for the Anybus CompactCom device:
NN: Description
0x00: Instance of a device type
0x01:
SerialNumber property of the device instance
0x02:
RevisionCounter property of the device instance
0x03:
Manufacturer property of the device instance
0x04:
Model property of the device instance
0x05: DeviceManual property of the device instance
0x06:
DeviceRevision property of the device instance
0x07: SoftwareRevision of the device instance
0x08: HardwareRevision of the device instance
0x09:
Instance of the DeviceType_ParameterSet of the OPC UA DI namespace. A
component of the device instance.
Node ID Browse name
0x00010000 CompactCom40Type
Description
CompactCom40 type definition based on OPC UA DI
DeviceType
