Anybus CompactCom 40 Network Manual page 125

CIP Objects
Instance Attributes
# Name Access
1 Status Get
2 Get
Configuration
Capability
3
Configuration Get/Set
Control
4 Get
Physical Link
Object
5
Interface Get/Set
Configuration
6 Host Name
Get/Set
8
TTL Value Get/Set
9 Set
Mcast Config
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Type
Value
-
DWORD
-
DWORD
-
DWORD
-
Struct of:
UINT (Path size) 0002h
Padded EPATH 20 F6 24 03h
Struct of:
UDINT (IP)
UDINT (Mask)
UDINT (GW)
UDINT (DNS1)
UDINT (DNS2)
STRING
(Domain)
-
STRING
USINT 1
Struct of:
Comments
Bit: Meaning:
(reserved, set to 0)
0–3
When set to h, attribute #5 contains valid
configuration from DHCP or non-volatile storage.
When set to 2h, attribute #5 contains valid
configuration from hardware settings. Remaining
values are reserved for future use.
4
Multicast pending if set to 1.
5
Interface configuration pending if set to 1. A new
configuration will be loaded at the next reset.
6
AcdStatus. Set to 1 if an address conflict is
detected. Address conflict detection is enabled/
disabled in attribute #10.
7
AcdFault
8–31
(reserved, set to 0)
Bit: Meaning:
0-1:
Always 0. For more information, consult the CIP
specifications.
2:
If set to 1, the device is capable of acting as a
DHCP client. The bit is set to 0 if attribute #24
(Enable DHCP Client) is disabled in the
Host Object (F9h), p. 209
3:
Always 0. For more information, consult the CIP
specifications.
4:
The 'Configuration Settable'-bit reflects the value
of instance attribute #9 in the "EtherNet/IP Host
Object (F8h)" on page 161.
5:
The module is hardware configurable when this
bit is set to 1. The bit will be set if any of the
address attributes is set in the Network
Configuration Object (04h) during setup or if
attribute #6 (Hardware configurable address) in
the Application Object (FFh) is set.
6:
Always 0. For more information, consult the CIP
specifications.
7:
If set to 1, the device is capable of detecting
address conflicts. The bit is set to 0 if address
conflict detection is disabled in the Ethernet Host
Object, see page 209
8 - 31:
(reserved, set to 0)
Meaning
Value:
0:
Configuration from non-volatile memory
2: Configuration from DHCP
-
-
Path to Ethernet Link Object, Instance #3
-
IP address
Subnet mask
Default gateway
Primary DNS
Secondary DNS
Default domain
Host name of Anybus module
TTL value for EtherNet/IP multicast packets
IP multicast configuration.
123 (244)
Ethernet
SCM-1202–069 1.9 en-US
