Host Application Objects
14.8

Sync Object (EEh)

Category
Extended
Object Description
The Anybus CompactCom 40 EtherNet/IP does not support CIP Sync. This object is only used to store the cycle
time for the last established IO connection that consumes data.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
The attributes are represented on EtherNet/IP as follows:
# Name
1
Cycle time
2–8
(not implemented)
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Get_Attribute
Get_Attribute
Set_Attribute
Access Data Type
UINT32
Get/Set
Description
The RPI for the last established IO connection that consumes data
(O→T RPI)
193 (244)
SCM-1202–069 1.9 en-US
