Anybus Module Objects
Instance Attributes (Sockets #1...Max. no. of instances)
Extended
# Name
1
Socket Type
2 Port
3 Host IP
4 Host port
5 TCP State
6
TCP RX bytes
7
TCP TX bytes
8 Reuse address
9
Keep alive
10 IP Multicast TTL
11
IP Multicast Loop
12
(reserved)
13
TCP No Delay
14 TCP Connect
Timeout
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Description
Get UINT8
Value:
00h
01h
02h
03h
Get UINT16
Local port that the socket is bound to
Get UINT32 Host IP address, or 0 (zero) if not connected
Get UINT16
Host port number, or 0 (zero) if not connected
Get UINT8
State (TCP sockets only):
Value
00h
01h
02h
03h
04h
05h
06h
07h
08h
09h
Ah
Get UINT16
Number of bytes in RX buffers (TCP sockets only)
Get UINT16
Number of bytes in TX buffers (TCP sockets only)
BOOL Socket can reuse local address
Get/Set
Value
1
0
BOOL
Get/Set Protocol probes idle connection (TCP sockets only).
If the Keep alive attribute is set, the connection will be probed for the
first time after it has been idle for 120 minutes. If a probe attempt
fails, the connection will continue to be probed at intervals of 75s.
The connection is terminated after 8 failed probe attempts.
Value
1
0
UINT8 IP Multicast TTL value (UDP sockets only).
Get/Set
Default = 1.
BOOL
Get/Set IP multicast loop back (UDP sockets only)
Must belong to group in order to get the loop backed message
Value
1
0
BOOL
Get/Set Don't delay send to coalesce packets (TCP).
Value
1
0
UINT16 TCP Connect timeout in seconds (default = 75s)
Get/Set
Socket Type
SOCK_STREAM, NONBLOCKING (TCP)
SOCK_STREAM, BLOCKING (TCP)
SOCK_DGRAM, NONBLOCKING (UDP)
SOCK_DGRAM, BLOCKING (UDP)
State/Description
CLOSED Closed
LISTEN Listening for connection
SYN_SENT Active, have sent and received SYN
SYN_RECEIVED Have sent and received SYN
ESTABLISHED Established.
CLOSE_WAIT Received FIN, waiting for close
FIN_WAIT_1 Have closed, sent FIN
CLOSING Closed exchanged FIN; await FIN ACK
LAST_ACK Have FIN and close; await FIN ACK
FIN_WAIT_2 Have closed, FIN is acknowledged
TIME_WAIT Quiet wait after close
Meaning
Enabled
Disabled (default)
Meaning
Enabled
Disabled (default)
Meaning
Enabled (default)
Disabled
Meaning
Delay (default)
Don't delay (turn off Nagle's algorithm on socket)
