CIP Objects
Instance 64h Attributes (Producing Instance)
The instance number for this instance can be changed by implementing the corresponding attribute in the
EtherNet/IP Host Object.
# Name Access
3 Get
Produced Data
4 Size Get
See also...
Network Data Exchange, p. 13
EtherNet/IP Host Object (F8h), p.
Instance 96h Attributes (Consuming Instance)
The instance number for this instance can be changed by implementing the corresponding attribute in the
EtherNet/IP Host Object.
# Name Access
3 Produced Data Set
4 Size Get
See also...
Network Data Exchange, p. 13
EtherNet/IP Host Object (F8h), p. 200
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Type
Value/Description
Array of BYTE This data corresponds to the Write Process Data.
UINT Number of bytes in attribute 3
200(Instance attribute #7)
Type
Value/Description
Array of BYTE This data corresponds to the Read Process Data.
UINT
Number of bytes in attribute 3
(Instance attribute #8)
