CIP Objects
Instance Attributes
Each instance corresponds to an instance within the Application Data Object (for more information, please
consult the general Anybus CompactCom 40 Software Design Guide).
# Name Access
1 Name Get
2 ABCC Data Get
type
3 No. of Get
Elements
4 Descriptor Get
5
Value Get/Set
6 Get
Max Value
7 Min Value Get
8 Get
Default Value
9 Get
Number of
subelements
Attributes #5–8 are converted to/from CIP standard by the module
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Type
Value/Description
SHORT_STRING Parameter name (Including length)
Array of USINT Data type of instance value
USINT Number of elements of the specified data type
Array of USINT Bit field describing the access rights for this instance
Bit: Meaning:
0 1 = Get Access
1 1 = Set Access
2 (reserved, set to 0)
3 1 = Write process data mapping possible
4 1 = Read process data mapping possible
5 1 = NVS parameter
6 1 = Data notification enabled
Determined by Instance value
attributes #2, #3
The maximum permitted parameter value.
and #9
The minimum permitted parameter value.
The default parameter value.
Array of UINT Number of subelements in the ADI. Default value is 1 unless implemented in
the application.
The size of the array depends on attribute #3.
