CIP Objects
7.12

ADI Object (A2h)

Category
Extended
Object Description
This object maps instances in the Application Data Object to EtherNet/IP. All requests to this object will be
translated into explicit object requests towards the Application Data Object in the host application; the re-
sponse is then translated back to CIP-format and sent to the originator of the request.
The ADI Object can be disabled using attribute 30 in the EtherNet/IP Host Object (F8h). This attribute can al-
so be used to change the ADI Object number.
See also ..
• Application Data Object (see Anybus CompactCom 40 Software Design Guide)
• Parameter Object (0Fh), p. 37
• EtherNet/IP Host Object (F8h), p. 88
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max Get
Instance
3 Number of Get
instances
For information about the Application Data Object, please consult the Anybus CompactCom 40 Software De-
sign Guide.
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
(CIP Object)
Get_Attribute_Single
Get_Attribute_Single
Set_Attribute_Single
Type Value
UINT 0002h (Object revision)
UINT Equals attribute #4 in the Application Data Object
UINT Equals attribute #3 in the Application Data Object
46 (144)
SCM-1202-019-EN 1.6
