Host Application Objects
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3
Number of instances
4
Highest instance no.
11 Current Energy Saving
Mode
12 Remaining time to
destination
13 Energy consumption to
destination
14 Transition to "Power
off" mode supported
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Get_Attribute
StartPause
EndPause
Preview_Pause_Time (not PROFINET)
Get_Attribute
Access Data Type
Get Array of CHAR
Get UINT8
Get UINT16
Get UINT16
Get UINT16
Get UINT32
Get FLOAT
Get BOOL
Value
"Energy Control"
02h
-
Highest created instance number. Maximum value is 8.
Instance number of the currently used Energy saving mode. During a
mode transition the new Energy saving mode shall be presented.
"Ready to operate" will equal instance #1, and "Power off" mode will
equal Highest instance number.
When changing mode this parameter will reflect the actual time (in
milliseconds) remaining until the shift is completed.
If a dynamic value cannot be generated the static value for the
transition from the source to destination mode shall be used.
If the value is infinite, or unknown, the maximum value 0xFFFFFFFF
shall be used.
When changing mode this parameter will reflect the actual energy (in
kWh) which will be consumed until the shift is completed.
If a dynamic value cannot be generated the static value for the
transition from the source to destination mode shall be used.
If the value is undefined the value 0.0 shall be used.
Indicates whether transition to "Power off" mode is supported or not.
0:
Not supported
1: Supported
