Anybus Module Objects
13.5

Network Configuration Object (04h)

Category
Extended
Object Description
This object holds network specific configuration parameters that may be set by the end user. A reset command
(factory default) issued towards this object will result in all instances being set to their default values.
If the settings in this object do not match the configuration used, the Module Status LED will flash red to
indicate a minor error.
As soon as the used combination of IP address, Subnet mask and Gateway is changed, the module informs the
application by writing the new set to instance #1, attribute #16 in the Ethernet Host Object (F9h).
The object is described in further detail in the Anybus CompactCom 40 Software Design Guide.
See also...
• Communication Settings, p. 10
• TCP/IP Interface Object (F5h), p. 122
• Ethernet Link Object (F6h), p. 125
• Ethernet Host Object (F9h), p. 209
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
3
Number of instances
4 Highest instance
number
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
(CIP-object)
Get_Attribute
Reset
Get_Attribute
Set_Attribute
Get_Enum_String
Access Data Type
Get UINT16
Get UINT16
Value Description
25
Supported number of instances
56 Highest instance number
134 (244)
