Anybus Module Objects
13.4

Network Object (03h)

Category
Basic
Object Description
For more information regarding this object, consult the general Anybus CompactCom 40 Software Design Guide.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Basic
# Name
1
Network type
2
Network type string
3
Data format
4 Parameter data support Get
5
Write process data size
6
Read process data size
7
Exception Information
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Get_Attribute
Get_Attribute
Set_Attribute
Get_Enum_String
Map_ADI_Write_Area
Map_ADI_Read_Area
Map_ADI_Write_Ext_Area
Map_ADI_Read_Ext_Area
Access Type
Get UINT16
Get
Array of CHAR
Get ENUM
BOOL
Get UINT16
Get UINT16
Get UINT8
Value
00ABh (EtherNet/IP Beacon Based 2–port + IIoT)
"Ethernet/IP(TM)"
00h (LSB first)
True
Current write process data size (in bytes)
Updated on every successful Map_ADI_Write_Area. (Consult the
general Anybus CompactCom 40 Software Design Guide for further
information.)
Current read process data size (in bytes)
Updated on every successful Map_ADI_Read_Area. (Consult the
general Anybus CompactCom 40 Software Design Guide for further
information.)
Additional information available if the module has entered the
EXCEPTION state.
Value: Meaning:
No information available
00h
01h Invalid assembly instance mapping
02h Missing MAC address (Only valid for Anybus IP)
