Host Application Objects
# Name
4 Cycle Time
5 FW upgrade in progress Set
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Default Value
-
Get UINT8
BOOL
False
Comment
Communication cycle time between the Anybus and
the Safety module in milliseconds.
Note: The host application shall never implement
this attribute when using the IXXAT Safe T100.
Valid values:
• 2 ms
• 4 ms
• 8 ms
• 16 ms
If another value is set in this attribute the Anybus
will enter Exception state.
Optional attribute; If not implemented the minimum
cycle time for the chosen baud rate will be used:
• 2 ms for 1020 kbit/s
• 2 ms for 1000 kbit/s
• 4 ms for 625 kbit/s
The Anybus CompactCom validates the cycle time
according to the minimum values above. If e.g. baud
rate is 625 kbit/s and the cycle time is set to 2 ms
the Anybus CompactCom will enter the EXCEPTION
state.
Indicates if the Anybus CompactCom is upgrading
the connected Safety module firmware. This means
that the Anybus CompactCom will stay in the NW_
INIT state longer than normal.
